The BETAFPV 1506 3000KV Brushless Motor is designed for powerful 36S FPV drones and toothpick builds in the 4″ to 5″ range. Whether you’re building a high-thrust freestyle quad or a long-range ultralight, this motor offers exceptional power-to-weight efficiency and smooth performance.

With a compact frame size of 21.321.327.6mm, a 1.5mm shaft, and 36S input voltage, the 1506 3000KV motor is perfect for frames like the TWIG Mutant, ET5, and X-Knight. It pairs well with props ranging from 3-inch to 5-inch, making it highly versatile for both racing and cinematic freestyle setups.

Key Features:

• KV Rating: 3000KV optimized for 36S LiPo input

• Weight: Just 16.2g per motor

• Shaft Diameter: 1.5mm

• Durable Construction: Robust M2 mounting pattern

• Flexible Build Options: Supports both 4S and 6S builds for high-thrust performance

• Pre-soldered 80mm 24AWG wires for convenient installation

Specifications:

Recommended Configuration (Not Included):

• Flight Controller: BETAFPV Toothpick F4 20A AIO

• Propellers: 3″5″ prop range

• Battery: 4S6S LiPo (e.g., 450mAh 4S 75C)

• Frames: TWIG Mutant / TWIG ET5 / X-Knight

Package Includes:

• 4 1506 3000KV Brushless Motors

• 1 Pack of M2 Mounting Screws

BETAFPV 1506 3000KV brushless motor for FPV drones, dimensions: 40mm length, 21mm width, 14mm height.

C23 1506 3000KV motor specs with GF D76 5B propeller. Voltage 16V, current 0.93-17.41A, thrust 50-485g, efficiency 3.36-1.74 g/W, speed 8414-31578 RPM, input power 14.88-279.30W.

BETAFPV 1506 3000KV brushless motors for 4-5 inch FPV toothpick drones, set of four.
