5.8GHz 3W 48CH VTX SPECIFICATIONS

Brand Name: Mitoot

Is Electric: No battery

Origin: Mainland China

Material: Metal

Recommend Age: 14+y

RC Parts & Accs: Speed Controllers

Size: 30.5*30.5

For Vehicle Type: Airplanes

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: 5.8G 3W VTX

Remote Control Peripherals/Devices: MOTOR

Tool Supplies: VTX 48CH 3000mW

Quantity: 1 pcs

Technical parameters: Value 2

Model Number: 5.8G 5.8GHz 3W Video Transmitter

Four-wheel Drive Attributes: 2.5W VTX

Wheelbase: Screws

for: Airplane

Place of Origin: Guangdong, China (Mainland)

Radio Control Style: RC Model

Power Source: Electric

Type: Helicopter

1. 48CH 5.8G frequency range: (A.B.E.F.R.L; 5362MHz-5945MHz);

2. Max power: 3W (25mW/1000mW/2000mW/3000mW adjustable);

3. Input voltage: DC 7V-36V, supporting 2-8S battery input

4. Antenna connector: MMCX

5. Smart audio: IRC Tramp

6. Heat-dissipating method: aluminum alloy heat sink&fan

7. Hole spacing: 30.5mm*30.5mm /3.15mm

8. Dimension: 37.7mm*36.1mm*11mm

9. Weight: 16g

Function introduction:

1. Channel indicator: Red LED

2. Band indicator: Blue LED

3. Power level indicator: Green LED

4. Band and channel changer button

5. Power changer button

6. 1.0 6P Power connector

7. MMCX antenna connector

Notice: The transmitter is equipped with temperature protection function. When the temperature of transmitter is higher than 100, the RF power of the Transmitter will be lowered for one level. If the temperature is still greater than 100, the power can be lowered for another level until the lowest power (25mW) is reached; at this time, the temperature of the Transmitter module will drop. When the temperature is lower than 95, the Transmitter power will return to the originally power level.
