SPECIFICATIONS

Brand Name: akk

Origin: Mainland China

Material: Composite Material

Use: Vehicles & Remote Control Toys

Quantity: 2

Model Number: VX171

VX171 Super Mini 5.8G 40CH 25mW FPV Transmitter–2PCS

Specificaiton:
Item name: VTX01 Super Mini FPV Transmitter
Output power: 25mW
Input voltage: 3.2-5.5V
5V camera supply, 300mA (MAX)
Video system: NTSC/PAL
Antenna dimensions: 55mm x 5mm diameter
Antenna: IPEX
Frequency: 5.8GHz bands 40 channel, with Raceband: 5658-5917MHz
Size: 20*14mm (L*W)
Weight: 2.8g

Operation:
Three adjustable gears, on/off switch, CH, FR automatically cycle display three gears on LED after power on.
Short press button to adjust “CH” , 1-8 adjustable.
Press and hold button 2s, transfer to FR, A, B, E, F, R adjustable, then short press button to adjust FR.
Press and hold button 5s to adjust on/off, “0” stands for “off”, and “=” stands for “on”.

Feature:
Super mini size and light weight
Five bands 40 channels with Raceband, show on LED Digital Display

Package Included:
1 X Transmitter module
1 X IPEX antenna

SV OuT CAM GND 3.2-5.5V Video GND LED display Antenna Button Press 1S, select CH Press 2S,select FR Press 2

The 5.8GHz IPEX antenna, designed for this transmitter, offers a more robust alternative to traditional clover-leaf antennas and features a lighter weight construction.

This mini FPV transmitter operates on 5.8GHz with 40 channels, featuring an output power of 25 milliwatts. It requires an input voltage of 3.2-5.5 volts and has a maximum camera supply current of 30mA. The video system supports NTSC format.
