Note:We default to send white shell, out diameter of arms 40mm .if you need red shell , or out diameter of arms 35mm, pls contact us or leave a message. thanks.EFT E410P 10L Agriculture Drone ParametersWheelbase1416mmTank capacity10LFrame weight6KGFull loa
Note:
We default to send white shell, out diameter of arms 40mm .
if you need red shell , or out diameter of arms 35mm, pls contact us or leave a message. thanks.
| Wheelbase | 1416mm |
| Tank capacity | 10L |
| Frame weight | 6KG |
| Full load weight | 26KG |
| Expand Size | 1781*1781*567MM |
| Folded size | 658*700*567MM |
| Flight time | 15-35min |
| Waterproof | IP67 |
| Recommended motor | X8 + 30inch propeller |
| Recommened Battery | 16000-22000MAH (12S) |
Package Included:
Package 1:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Package 2:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Hobbywing X8 Power system x 4 (2CW+2CCW)
Package3:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Brushless spraying system x 1(Hobbywing 5L pump)
Hobbywing X8 Power system x 4 (2CW+2CCW)
Package4:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Brushless spraying system x 1
(Y-type nozzle+Hobbywing 5L pump)
Hobbywing X8 Powersystem x 4 (2CW+2CCW)
Package 5:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Hobbywing 5L Brushless spraying system x 1
Hobbywing X8 Propulsion system x 4 (2CW+2CCW)
JIYI K3A Pro Flight controller x1
Skydroid H12 x 1
Camera x1
Tattu 12S 16000mah Battery x 1
SKYRC PC1500 12S Battery Charger x1
Accessories Bag x 1
Flow meter x1
Package 6:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Hobbywing 5L Brushless spraying system x 1
Hobbywing X8 Propulsion system x 4 (2CW+2CCW)
JIYI K3A Pro Flight controller x1
Skydroid T12 x 1
Camera x1
Tattu 12S 16000mah Battery x 1
SKYRC PC1500 12S Battery Charger x1
Accessories Bag x 1
Flow meter x1
Package 7:
EFT E410P 4 Axis 10L Agriculture Drone frame x 1
10L water tank x 1
Hobbywing 5L Brushless spraying system x 1
Hobbywing X8 Propulsion system x 4 (2CW+2CCW)
JIYI K++ Flight controller x1
Skydroid H12 x 1
Camera x1
Tattu 12S 16000mah Battery x 1
SKYRC PC1500 12S Battery Charger x1
Accessories Bag x 1
Flow meter x1
The new E-series upgrade products adopt a new one-piece molding process to simplify the fuselage from dozens of original parts into a whole body. The body is made of high-strength, impact-resistant materials, which are strong and resistant fall
The body adopts streamlined design, bright red coating, simple and beautiful appearance, and the surface is UV-treated, scratch-resistant, corrosion-resistant, overall dust-proof and waterproof, and can be washed directly with water
The drone’s body features a streamlined design with a bright red coating, providing a simple yet beautiful appearance. The surface has undergone UV treatment, making it scratch-resistant, corrosion-resistant, and overall dust-proof, allowing for direct washing with water and even use in washing clothes.
The EFT E410P features a detachable camera mount located at the front of the drone’s frame. This allows for easy installation and removal as needed, providing flexibility and convenience when using the drone with your preferred camera.
The EFT E410P features an integrated power supply wiring system that separates signal and power supplies, effectively reducing electromagnetic interference (EMI) and ensuring stable operation.
The EFT E410P’s arms feature a classic folding design with a cross-folding and staggered folding mechanism. This innovative design allows for a compact folded size, making it easier to transport and store the drone.
Product Information:Package Size: 71mm x 440mm x 210mmMain Body Accessories: [Insert actual accessories list]Contact Information: EFT Effort-Tech Electronic Technology Co., Ltd. – [www.vuleffort-tech.com](http://www.vuleffort-tech.com)Customer Service Hotline: 0088-XXX-XXXX (insert actual hotline number)
Product Information:Main Body Accessories: [Insert actual accessories list]Contact Information: EFT Effort-IECH, EFT Electronic Technology Co., Ltd.
EFT E410P 4 Axis 10L Farm Drone Agriculture Spraying Drone with Hobbywing X8Propulsion Systems and brushless spraying systems. We offer flight controller, radio, battery and charger. You can choose the one you are interested to make the complete version. The drone with the components is not assembled, you need to assemble and tune it by yourselt.
The E410P Series agriculture drones continues the classic design elements of the old E series. It adopts red and blue color matching, a streamlined body design, and the whole body is waterproof, without fear of high pressure washing. The new P series upgrade product adopts a new integrated molding process. Complex to simple, the fuselage is integrated from dozens of original parts into a whole, and the fuselage is made of high-strength and impact-resistant materials, which are strong and anti-fall.
The force-bearing structure of the fuselage adopts a double fixing method of clamping and limiting at many key points, so that the entire fuselage will not cause structural displacement due to long-term use, and it also makes installation and positioning easier.
There reserved a detachable camera installation parts in front of the fuselage, which can be installed or closed according to own needs.
The power distribution board in the center of the fuselage integrates all power supply plugs to separate the power supply from the signal and minimize interference
The new product continues the classic foldable body design, using threaded locking and folding parts, which are stable and not loose, and the volume is small after folding, which is convenient for transportation and transition.
Specifications:
Digonal Wheelbase: 1416mm
Folding Dimensions: 700x799x567mm
Unfolded Dimensions: 1780x1780x567mm
Arm Diameter: 40mm
Payload: 10L
Frame Weight: 6kg
Frame with power equipement: about 12kg
Max take off weight: 26kg
Spray lance width: 1800mm
Spraying swath: 4-3m (flight height is 1.5m to 2m)
Main arm length:216mm
Power source: Battery
Power Connector: AS150U
Flight time: 10 to 15 minutes (with 12S 16000mah Lipo)
Flight speed: 0-12M/S
Spray speed: 0-8M/S
Spray flow: 0.2-4L/min
Flying downward airflow: 4-15m/s
Operation temperature:10~50
Hobbywing X8 Power System for Agricultural Drones
| X8 Power System for Agriculture Drones | ||
| Specifications | Max. Thrust | 15.3kg/Axis (48V, Sea Level ) |
| Recommended LiPo Battery | 12S LiPo | |
| Recommended Takeoff Weight | 5-7kg/Axis(48VSea Level) | |
| Combo Weight | 1040g | |
| Waterproof Rating | IPX7 | |
| Operating Temperature | -20~65 | |
| Motor | Stator Size | 81*20mm |
| KV Rating | 100 rpm/V | |
| O.D of Carbon Fiber Tube | 35mm/30mm (*Tube Adapter will be Needed) | |
| Bearing | NSK Ball Bearing (Waterproof) | |
| ESC | Recommended LiPo Battery | 6-12S LiPo |
| PWM Input Signal Level | 3.3V/5V (Compatible ) | |
| Throttle Signal Frequency | 50-500Hz | |
| Operating Pulse Width | 1100-1940 s (Fixed or cannot be Programmed ) | |
| Max. Input Voltage | 52.2V | |
| Max. Input Current (Cont.) | 80 A(w/ Good Heat Dissipation ) | |
| Max. Peak Current (10s) | 100 A (w/ Good Heat Dissipation ) | |
| BEC | No | |
| Nozzle Mounting Holes | 28.4mm-2*M3 | |
| Propeller | DiameterThread Pitch | 29×11 inch |
| Weight | 180g |
