Description

HPS-HC701 S.Bus2 High-Voltage Low-Profile cyclic Servo

High Performance cyclic Servo with Brushless Motor (1520uS/760uS switchable) (01102382-3)

FEATURES:
Suitable for RC helicopters 500-800 3D/F3C
Programmable/HV Brushless Servo.
Custom New high power Brushless Motor.
Supports 760uS (Factory Default, able to be set to 1520uS w/ GPB-1 v4.3 .)
Programmable and compatible with S.Bus and S.Bus2 systems.
Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
Upper/middle/bottom: Aluminum Case

1520uS
Speed0.07sec/60(7.4V) 0.08sec/60(6.6V)

Torque30.0gfcm(7.4V) 26.5kgfcm(6.6V)
416.6ozfin(7.4V) 368.0ozfin(6.6V)

760uS
Speed0.07sec/60(7.4V) 0.08sec/60(6.6V)

Torque27.0kgfcm(7.4V) 24.0kgfcm(6.6V)
375.0ozfin(7.4V) 333.3ozfin(6.6V)

Dimensions/Weight40.521.026.2mm/54g (1.590.831.03in)

RATED VOLTAGE:
DC 6.0V-7.4V

OPERATING VOLTAGE:
DC 4.8-8.4V

NO DRY BATTERY USE
