MAD M25 IPE Drone Motor SummaryThe MAD M25 IPE V1.0 Drone Motor is a high-performance motor designed for industrial and agricultural drones. It features a robust construction with Japan-sourced anticorrosive stator, capable of withstanding high temperature
The MAD M25 IPE V1.0 Drone Motor is a high-performance motor designed for industrial and agricultural drones. It features a robust construction with Japan-sourced anticorrosive stator, capable of withstanding high temperatures (up to 180C for varnished wire and 150C for magnets). The motor provides excellent centrifugal heat dissipation and is IP35 rated for protection. It supports a significant power output of 10878W, with a maximum thrust of 39.4 kg and torque of 19.9 Nm. Designed for use with a 12S lipo battery, it is suitable for heavy-lift drones, supporting UAV take-off weights up to 96 kg for octocopters. The motor comes with recommended accessories and is compatible with the MAD AMPX 200A ESC.
| Parameter | Value |
|---|---|
| Motor Model | MAD M25 IPE V1.0 |
| Number of Pole Pairs | 15 |
| Stator | Japan / Anticorrosive |
| Varnished Wire Degree | 180C |
| Motor Size | D: 118 49.9 mm |
| Magnet Degree | 150C |
| Degree of Protection | IP35 |
| Cable Length | 150 mm (extended Enameled wires) |
| Centrifugal Heat Dissipation | YES |
| Rotor Balance | 10 mg |
| Propeller Mounting Holes | D: 20 M34, D: 23 M44 |
| Motor Balance | 20 mg |
| Shaft Diameter | IN: 15 mm |
| Motor Mounting Holes | D: 50 M44 |
| Bearing | EZO 6902ZZ *2 |
| Disruptive Test | 500 V |
| Additional Accessories | Propeller Plate *2, Locate Pin *1, 8.0mm Bullet Connector *3, Heat Shrinkable Tube 3, M412mm 4 Motor Screws, M316mm 4 Propeller Screws, M420mm *4 Propeller Screws, Sticker *2 |
| Parameter | Value |
|---|---|
| RPM/V | 100 KV |
| Nominal Voltage | 12S lipo battery |
| No Load Current | 4.3A / 30V |
| Internal Resistance | 16.7m |
| Motor Weight | 1280 g |
| Product Boxed Weight | 1402g (200 x 150 x 70 mm) |
| Maximum Current | 230.3 A |
| Maximum Power | 10878W |
| Maximum Thrust | 39.4 kg |
| Maximum Torque | 19.9 Nm |
| Recommended ESC | MAD AMPX 200A (5-14S) |
| Recommended Propellers | 40×13.1 |
| UAV Take-off Weight | 125~40 / 48kg — Quadcopter 72kg — Hexacopter 96kg — Octocopter |
| Single Rotor Take-off Weight | 10kg ~ 15kg |
MAD M Series motors are the flagship motors designed specifically for large multi-rotor electric paragliders, large agricultural tethered VTOLs, UAVs. Used for aerial photography, mapping, electric paragliding, agricultural spraying, surveying or anything in between where professional industrial grade propulsion systems are required. This type of motor is made with industrial grade components, it is for the long flight time multirotor hexacopter octocopte for the long flight time tethered drone.
