MAD VAX 5330 VTOL Drone Motor SummaryThe MAD VAX 5330 VTOL Airplane Drone Motor is a high-performance motor designed for UAV applications. It features a robust design with anti-corrosive stator material and rain protection, making it suitable for various e
The MAD VAX 5330 VTOL Airplane Drone Motor is a high-performance motor designed for UAV applications. It features a robust design with anti-corrosive stator material and rain protection, making it suitable for various environmental conditions. The motor is available in two KV ratings (220KV and 260KV), each offering different specifications tailored to specific needs.
220KV Motor:
260KV Motor:
Both versions are equipped with high-quality bearings, independent centrifugal heat dissipation, and excellent balance. They are designed for heavy-lift drones, supporting take-off weights up to 44 kg for octocopters.
| Parameter | Value |
|---|---|
| Motor Model | MAD VAX 5330 EEE V1.0 |
| Number of Pole Pairs | 7 |
| Stator | TAIWAN / Anticorrosive |
| Varnished Wire Degree | 180C |
| Motor Size | D: 61.1 84 mm |
| Magnet Degree | 150C |
| Degree of Protection | Rain protection |
| Cable Length | 150 mm 14# Awg(Black) silicone |
| Centrifugal Heat Dissipation | Independent |
| Rotor Balance | 5 mg |
| Propeller Mounting Holes | D: 31 M34, D: 20 M34 |
| Motor Balance | 10 mg |
| Shaft Diameter | IN: 8 mm |
| Motor Mounting Holes | D: 30 M44, D: 44 M44 |
| Bearing | EZO 688ZZ2 / NMB 19801 |
| Disruptive Test | 500 V |
| Additional Accessories | Prop Adapter(M8) 1, Propeller Plate 1, 4.0mm Bullet Connector3, Heat Shrinkable Tube3, M412mm 4 Motor Screws, M38mm 4 Prop Adapter Fixing Screws, M8 Nut1, Sticker1 |
| Parameter | 220KV | 260KV |
|---|---|---|
| RPM/V | 220KV | 260KV |
| Nominal Voltage | 12S lipo battery | 12S lipo battery |
| No Load Current | 1.35A / 30V | 1.6A / 20V |
| Internal Resistance | 45m | 21m |
| Motor Weight | 570 g | 564 g |
| Product Boxed Weight | 750g (110 x 110 x 65 mm) | 732g (110 x 110 x 65 mm) |
| Maximum Current | 70.8 A | 97 A |
| Maximum Power | 3263W | 4377W |
| Maximum Thrust | 11.2 kg | 12.8 kg |
| Maximum Torque | 3 Nm | 3.5 Nm |
| Recommended ESC | MAD AMPX 80A (5-14S) | MAD AMPX 120A (5-14S) |
| Recommended Propellers | 18×12, 19×10, 20×10, 17x8X3 | 18×12, 19×10, 20×10, 17x8X3 |
| UAV Take-off Weight | 12S-20/ 17kg–Quadcopter 25.5kg–Hexacopter 34kg–Octocopter |
12S-20/ 22kg–Quadcopter 33kg–Hexacopter 44kg–Octocopter |
| Single Rotor Take-off Weight | 4kg ~ 5kg | 5kg ~ 6kg |
