MKS Servo HV747 HA Series

High Torque Servo for Airplane / Jet / Electric Plane

– 12 x 20 mm coreless motor, High efficient, More durable.
– 9mm VR, Ultrahigh-resolution.
– New type gear structure, Tiny backlash, High durable.

Torque (kg-cm)11.8 (6.0V) / 13.8 (7.4V) / 15 (8.2V)

Torque (oz-in)163.9 (6.0V) / 191.6 (7.4V) / 208.3 (8.2V)

Speed 0.17 s (6.0V) / 0.14 s (7.4V) / 0.13 s (8.2V)

Stall Current (at locked load)2.3A (6.0V) / 2.8A (7.4V) / 3.1A (8.2V)

Working Voltage 6.0V ~ 8.4V DC Volts

Working Frequency1520s / 333Hz

Dead Band 0.001 ms (Default)

Bearing 2* Ball Bearing

GearMetal Alloy Gear

Motor Coreless Motor

Wire Length 29.5 cm
