SPECIFICATIONSWheelbase: Bottom PlateUse: Vehicles & Remote Control ToysUse: Vehicles & Remote Control ToysUpgrade Parts/Accessories: Zoom CameraUnit Type: pieceTool Supplies: Zoom CameraTechnical parameters: KV1100Size: As descriptionRemote Control Periph
Wheelbase: Bottom Plate
Use: Vehicles & Remote Control Toys
Use: Vehicles & Remote Control Toys
Upgrade Parts/Accessories: Zoom Camera
Unit Type: piece
Tool Supplies: Zoom Camera
Technical parameters: KV1100
Size: As description
Remote Control Peripherals/Devices: Remote Controller
RC Parts & Accs: Zoom Camera
Package Weight: 0.1kg (0.22lb.)
Package Size: 5cm x 5cm x 5cm (1.97in x 1.97in x 1.97in)
Model Number: SMT10SQ3/SMT10SQ6
Material: EVA
Four-wheel Drive Attributes: Assemblage
For Vehicle Type: Airplanes
Brand Name: uuustore
18x daylight sensor with optical zoom function
Multiple thermal imaging pseudo color mode
Multi picture-in-picture mode, single HDMI outputZero-second real-time switching
Three-axis stabilization gimbal
PWM or SBUS command control
OSD menu tuning
Single TF card, two-way simultaneous recording
SMT18SQ3/Q6 combines 18x optical zoom camera, 384/640 thermal imaging system, and a high-precision 3-axisstabilizing gimbal. The camera supports picture-in-picture display, HDMI output, OSD set up, PWM control,SBUS control, and allows storing their data in local TF card. The video recording under visible light and infraredlight can work simultaneously with multiple picture-in-picutre displaying modes. By changing these modes,thezoom function will not be interrupted.
4M SENSOR 18x optical zooming, 1286 memory card, multiple-pseudo color modes, multiple picture-in-picture modes, mode switch in real time . axis stabilizing gimbal control, PWM/SBUS/Serial Port Control: Size: 120*155*175(mm), Weight: 785+10g .
|
model |
SMT18SQ3/Q6 |
|
|
Power Supply |
3S(DC12V) |
|
|
Power Consumption |
Dynamic condition 7.5W |
|
|
Working Status |
Jitter Angle |
Pitch and Roll: 0.02 |
|
|
Work Range |
Pitch range: -90to +90 |
|
Visible |
Sensor |
1/3 4M Pixes CMOS sensor |
|
|
Zoom |
18x HD optical zoom lens, f=4.7 to 84.6mm |
|
|
AF Time |
Support quick auto focus, timelapse < 1 sec |
|
|
Support Mode |
1080P 30fps, 720P 60fps |
|
|
Field Angle(FOV) |
D : WIDE 68.55% TELE 4.25% H : WIDE 54.85% TELE 3.45% V : WIDE 415% TELE 2.55% |
|
Infrared |
Resolution |
384*288/640*480 pixels |
|
|
Pix Spacing |
17m |
|
|
Measurement Option |
Highest temperature, lowest temperature, and over temperature alarm |
|
|
Wavelength |
8~14m |
|
|
(NETD) Thermal Sensitivity |
65mk@30 |
|
|
Field Angle |
19mm Lens; Angle: 32.0×24.2 |
|
|
Measurement(Optional) |
Center point, highest temperature, lowest temperature, temperaturedisplay, over-temperature alert |
|
|
Type |
Uncooled Micro Bolometer IR FPA Fabrication |
|
Device Size |
120mm155mm175mm |
|
|
Work Condition |
-10to +45/ 20% to 80% RH |
|
|
Weight |
825g (with metal damping board) |
‘
