• The T-MOTOR F90 2806.5 Brushless Motor is purpose-built for long-range and cinematic FPV quads, offering excellent performance and control across 5″, 6″, 7″, and 8″ platforms. With a large 2806.5 stator and premium construction, the F90 delivers powerful thrust, smooth throttle response, and high efficiency for both freestyle and cinematic flying styles.

  Available in two KV variants:

  • 1300KV: Ideal for 7″8″ propellers on 6S, optimized for endurance and payload.

  • 1500KV: Best paired with 6″7″ props for responsive freestyle agility and mid-range power.

  Key Specifications:

  Spec	F90 1300KV	F90 1500KV
  Rated Voltage	56S LiPo	56S LiPo
  Shaft Diameter	4mm	4mm
  Motor Weight	46.6g	36.7g
  Max Power (60s)	1059W	1089W
  Peak Current (60s)	45.1A	47.4A
  Configuration	12N14P	12N14P

  Why Choose the F90 2806.5:

  • Large stator for high torque and efficient power delivery

  • Designed for long range cinematic and freestyle builds

  • High durability with precise engineering from T-MOTOR

  • Reliable performance for heavier builds or extended flight time

  Recommended Applications:
  Perfect for cinelifters, long-range cruisers, and powerful freestyle rigs using 6S batteries and 6″ to 8″ props.

T-MOTOR drawing: 34.7mm, 19.7mm, 19, 33.4, M5, 4-M3; 46.6g.

T-MOTOR KV1300 and KV1500 specs: 46.6g/46.7g weight, 33.4*34.7mm dimensions, 20#AWG 230mm lead, 4mm shaft, 5-6S voltage, 0.95A/1.2A idle current, 45.1A/47.4A peak current, 1059W/1089W max power.

Test report for T-MOTOR F90 KV1300 with HQ 70403 propeller. Data includes throttle, thrust, voltage, current, RPM, power, efficiency, and operating temperature at various settings. Ambient temperature: 27C.

T-MOTOR GF 7042 performance data at various throttle levels, including thrust, voltage, current, RPM, power, efficiency, and operating temperature. Ambient temperature is 27C. Benchtest results for reference.

T-MOTOR HQ 70403 and F90 KV1500 GF 7042 performance data at various percentages, including voltage, current, power, RPM, torque, and efficiency, with ambient temperature at 27C.

T6143 motor performance data at various throttle percentages, including voltage, current, RPM, power, efficiency, and temperature. Ambient temperature: 27C. Benchtest reference values for comparison.

T-MOTOR product includes Motor KV1300 and Parts Bag. Verify contents before use; contact support if items are missing.

F90 motor offers longer flight time, weighs 41g, efficient KV1300/KV1500.

T-MOTOR design for FPV Cinelike X8 build, easy to carry heavier camera.

T-MOTOR excels for mountain surfing, coastline, and cinematic flight experiences.
