Overview

The XF Z-9B Drone Pod is a high-performance, quad-sensor payload designed for versatile aerial applications. Featuring a 30x optical zoom camera, 25mm 640×512 IR thermal camera, 2KM laser range finder, and a 200M laser lighting module, it provides unmatched imaging and tracking capabilities. The advanced 3-axis orthogonal gimbal ensures stabilization with an angular accuracy of 0.01. Equipped with AI multi-object detection and tracking, the XF Z-9B Drone Gimbal Camera offers precision tracking for persons and vehicles, enhancing mission efficiency in complex scenarios.

Key Features

• Quad-Sensor Configuration:

  • 30x Optical Zoom Camera with 4x digital zoom, enabling detailed observation at extended ranges.
  • 640×512 Thermal Camera with an 8-14m spectral band and sensitivity of <50mk for precise thermal imaging.
  • 2KM Laser Range Finder for accurate distance measurement.
  • 200M Laser Lighting Module ensures clear imaging in low-light or complete darkness.

• Advanced AI Tracking:

  • Tracks up to 50 objects simultaneously with a target identification rate 85%.
  • Target tracking size ranges from 16×16 to 256×256 px.
  • Low tracking deviation with a refresh rate of 30Hz and an output delay of <60ms.

• Enhanced Gimbal Stability:

  • 3-axis orthogonal mechanical stabilization with a controllable range of Pitch: -120 to +55, Roll: 40, Yaw: 360.
  • Max controllable speed of 200/s ensures smooth adjustments.

Specifications

General

Camera Systems

Laser Range Finder and Lighting Module

Storage and Video

Environmental Parameters

Applications

The XF Z-9B Drone Pod is designed for diverse industries:

• Public safety and law enforcement.
• Search and rescue missions.
• Environmental monitoring and protection.
• Infrastructure inspection and maintenance.

With its robust capabilities, the XF Z-9B Drone Gimbal Camera ensures mission success even in challenging conditions.

XF Z-9B Quad-Sensor Drone Pod features a 3-axis gimbal for stable footage. It includes multi-object detection and tracking, I2Ox zoom, thermal imaging, laser ranging, and lighting capabilities. Manufactured by Nanjing Xianfei Robot Technology Co., Ltd.

Multi-object detection and tracking with intelligent algorithms. The XF Z-9B Quad-Sensor Drone Pod features a 3-axis gimbal for stable footage.

The XF Z-9B Quad-Sensor Drone Pod features a 3-axis gimbal for stabilized footage and support for open-source autopilot systems, including Maulink protocol and MAVLINK micro air vehicle communication protocol.

XF Z-9B Quad-Sensor Drone Pod features a 3-axis gimbal with abundant interfaces supporting networking, UART control, and providing an SDK for network connectivity.

The XF Z-9B Quad-Sensor Drone Pod features a 3-axis gimbal with stabilization accuracy to 0.01, measuring 173×144 x 66mm and weighing 1158g.

The XF Z-9B Quad-Sensor Drone Pod features a 3-axis gimbal with continuous rotation on the yaw axis.

Real-time matrix and split keyboard, mouse multi-device monitor and control. Joystick controls the XF Z-9B Quad-Sensor Drone Pod 3-axis gimbal for smooth and precise aerial photography.
